YERTAI Electronic Load Tester, ET5406A+ 200W Programmable DC Load Testers 20A 120V Battery Capacity Detector in Charger, Liner Power, Grey

ET5406A+: Reted input: 200W/ 0-120V/ 0-20A The programmable DC electronic load provides 1mV/10mV, 1mA/10mA high resolution and precision with superior performance. It is equipped with 9 common modes and complete test functions, which can be widely used in charger, switching power supply, linear power supply, battery and otherproduction line testing. High-performance load: It provides CC, CV, CR, CP basic measurement modes It provides professional battery test; The Tran test mode can test the dynamic output performance of the power supply; The list test mode can simulate a variety of loading status changes; The short circuit test can be used to simulate load short circuit; Support external trigger input Built-in buzzer alarm; Maintain data storage in case of power failure; Remote operation via USB, It provides overcurrent, overvoltage, overpower, over temperature protection Standard accessories: US power plug*1 Power fuse * 2 User manual * 1

• 【ET5406A+ Single Channel Programmable Electronic Load Testers】provides 1mV/10mV, 1mA/10mA high resolution and precision with superior performance;Adopting LCD segment code screen with adjustable backlight;
• 【Remote Control】Support Communication with computer via USB port, please ask supplier to acquire software and SCPI if need.
• 【9 Common Testing Mode】CC, CV, CR, CP basic measurement modes,;Battery Test Mode, Dynamic Mode, Tran Test Mode，List Test Mode, Short Circuit Test;
• 【Other functions】Provides overcurrent, overvoltage, overpower, over temperature protection, input polarity reverse prompt；
• 【PACKAGING and AFTER-SALES】DC Electronic Load x1， output power cord x1, User manual x1; We provide ONE YEAR WARRANTY, please feel free to contact us if any question.
